PCB Stencil Capability
XFPCB stencil capability covers laser-cut stainless foils, step stencils for mixed pad geometries and optional coatings that improve paste release on fine-pitch openings.
Capability Focused on Paste Control
Stencils are a manufacturing tool, not artwork decoration. Our capability center is aperture accuracy, thickness options and special foil treatments that stabilize printing.
For product pages on electroform, nano-coat or step stencils, use the dedicated URLs linked below - this page summarizes what we can execute.
From Capability to Cut Foil
Engineer apertures
Apply pitch-appropriate reductions and thermal pad windows.
Fabricate
Laser cut, clean, coat if selected, inspect critical openings.
Deploy
Use in XFPCB SMT or ship framed/frameless to your line.
Capability Notes
- Electroformed nickel stencils are a different process - see the electroform page when that technology is required.
- Nano-coating helps release on fine apertures; it is optional, not automatic.
- Step locations must be defined from the pad map, not guessed.
- Stencil revision must follow PCB revision changes.
Capability Matrix
| Project Area | XFPCB Guidance |
|---|---|
| Laser-cut stainless | Standard SMT production and prototypes |
| Step stencil | Mixed large/small pad designs |
| Coating options | Improved paste release on fine openings |
| Integration | Cut for in-house PCBA or external shipment |
Choose the Right Stencil Path
Standard Laser Cut
Best default for most FR-4 SMT boards with moderate pitch.
Step Stencil
Use when one thickness cannot serve both tiny and oversized pads.
Coated Foil
Consider for stubborn fine-pitch paste release issues.
Useful Terms
- Laser-cut stencil
- Stainless foil apertures cut by laser.
- Step stencil
- Foil with local thickness steps.
- Nano-coating
- Surface treatment improving paste transfer.
- Electroform
- Additive nickel stencil process for ultra-fine needs.
